Chevrolet Colorado Towing Capacity by Year, Engine & Trim (2026 Chart)

Picture a 6,000-pound bass boat in the driveway behind a 2024 Colorado Z71. The truck looks ready. But does the spec sheet back it up? Tow ratings swing from 3,500 pounds on a base four-cylinder to 7,700 pounds with the right engine and options. Same year, same trim, two different ratings depending on axle ratio. This chart sorts it all out.

Quick Answer: The 2025 and 2026 Chevrolet Colorado tow up to 7,700 lbs with the 2.7L TurboMax and factory trailering package. Base WT and LT trims start at 3,500 lbs and can reach 7,700 lbs. The ZR2 caps at 6,000 lbs due to its desert-tuned suspension. Your certified number lives on the door jamb sticker, not the brochure.

Colorado Towing Capacity at a Glance: 2004-2026 Chart

Three generations tell different stories. The first replaced the S-10 with a 3.5L five-cylinder rated for 4,000 lbs. The second reset the bar in 2015. The current generation, on sale since 2023, runs a single 2.7L turbo in three output levels.

Generation	Years	Max Tow (lbs)	Engine
1st Gen	2004-2006	4,000	3.5L I5
1st Gen	2007	4,000	3.7L I5
1st Gen	2008-2012	6,000	5.3L V8
2nd Gen	2015	7,000	3.6L V6
2nd Gen	2016-2022	7,700	2.8L Duramax Diesel
3rd Gen	2023-2026	7,700	2.7L TurboMax

Match your model year to the engine and ceiling. Your actual number still lives on the door jamb sticker.

First Generation (2004-2012)

The early 3.5L five-cylinder Colorados topped out at 4,000 lbs. That worked for a small camper, not much else. In 2008, Chevy dropped the 5.3L V8 into the option list and pushed the rating to 6,000 lbs. That V8 truck remains a sleeper in the used market if you find one with clean frame rails.

Second Generation (2015-2022)

The reboot brought a real platform. The 3.6L V6 reached around 7,000 lbs. The 2.8L Duramax turbo-diesel arrived for 2016 and lifted the ceiling to 7,700 lbs, where it stayed. The base 2.5L four-cylinder held at 3,500 lbs through 2022.

Third Generation (2023-2026)

One block, three tunes. According to Chevrolet's official Colorado specifications page, the TurboMax variant produces 310 hp and 430 lb-ft of torque. Pair it with the trailering package and you reach the 7,700-lb ceiling.

Third-Generation Colorado Towing by Trim and Engine (2023-2026)

Most shoppers get tripped up here. The current generation runs a single 2.7L turbo block, but Chevy tunes it three ways depending on trim. Same displacement, different output, different tow rating.

Engine Output	HP	Torque	Trims	Max Tow (Properly Equipped)
2.7L Turbo	237 hp	259 lb-ft	WT, LT (base)	3,500 lbs
2.7L Turbo Plus	310 hp	390 lb-ft	LT (optional), Trail Boss, Z71	7,700 lbs*
2.7L TurboMax	310 hp	430 lb-ft	Trail Boss, Z71, ZR2	7,700 lbs (6,000 ZR2)

*Requires the factory trailering package.

A WT or LT off the lot with the base Turbo is rated for 3,500 lbs. To reach 7,700, the truck needs the upgraded output and trailering package. If you're shopping a used 2024 LT, ask the dealer to pull the build sheet before you commit.

The Trail Boss and Z71 are where most working owners land. Both ride on the Turbo Plus or TurboMax and both can pull the full 7,700. If you want covers shaped to factory seats for a fresh truck, our 2025 Chevy Colorado seat covers match the trim profiles for both.

2.7L Turbo vs. Turbo Plus vs. TurboMax: What Each Trim Gets

The base Turbo is the fleet motor. Turbo Plus is the volume-seller upgrade. TurboMax is standard on Trail Boss, Z71, and ZR2. The 430 lb-ft figure matters most for towing. Torque, not horsepower, holds a loaded trailer steady on a 6% grade.

ZR2 Towing Capacity: Why It Sits Lower

The ZR2 Crew Cab caps at 6,000 lbs. Same engine as the Z71, lower number. Why? Multimatic DSSV dampers, wider track, and suspension built for desert running, not load-bearing. Articulation wins here, tongue weight loses. If you tow more than a side-by-side trailer regularly, the Z71 is the smarter pick.

Second-Generation Colorado Towing by Engine (2015-2022)

This generation built the Colorado's towing reputation. Three engines, three different jobs.

Engine	Years	Max Tow (lbs)	Best Use
2.5L I4	2015-2022	3,500	Light utility, small trailer
3.6L V6	2015-2022	7,000	Mid-size camper, boat
2.8L Duramax Diesel	2016-2022	7,700	Heavy work, long grades

2.5L Four-Cylinder

The 2.5L is the work-fleet motor. Rated for 3,500 lbs throughout its run. It works fine for a single jet ski or a 5x8 utility trailer. Don't ask it to do more.

3.6L V6

The volume motor. Around 7,000 lbs when properly equipped. Most second-generation Colorados on the used market today are V6s, and most tow great if the previous owner didn't abuse the transmission.

2.8L Duramax Turbo-Diesel

The hero motor. It arrived for 2016 and put the Colorado at the top of the midsize class with 7,700 lbs. If you find a clean diesel example, it's worth the premium. Pull a 6,500-lb travel trailer with one and the torque curve makes the whole thing feel almost lazy. The grade isn't even there. Drivetrain matters too: 2WD configurations carry a slightly higher rating than 4WD on the same block because of the extra hardware weight.

The Trailering Package: What It Includes and Why It Matters

A 2025 Colorado WT off the lot with no options is rated for 3,500 lbs. The exact same trim with the factory trailering package checked at order time is rated for 7,700 lbs. Same truck. Same block if you also upgraded that. Different number on the door sticker.

The package typically includes:

• A frame-mounted hitch receiver (not the bumper-attached kind)
• A 7-pin or 4-pin wiring harness
• A heavy-duty transmission cooler
• Trailer sway control software
• Sometimes an upgraded rear axle ratio

A Reddit user in r/chevycolorado flagged the difference between a non-welded bumper receiver and the real frame-mounted unit. They're not the same. If your truck has a hitch hanging off the rear bumper instead of bolted to the frame, you do not have the trailering package. You have an accessory hitch. Big difference when you're loading 7,000 lbs.

To verify what your specific truck has, pull the window sticker from Chevy using the VIN, check the build sheet, or look for option code Z82 on older models. According to Chevrolet's trailering package documentation, the factory option is the mechanism for unlocking max tow ratings.

Payload, GVWR, GCWR, and Tongue Weight Explained

Tow rating is one number on a spec sheet. The other three matter just as much, and one of them will bite you before the tow rating ever does.

Payload capacity is what your truck can carry inside it. That means passengers, cargo in the bed, gear in the cab, plus the tongue weight pressing down on the hitch. Most current-generation Colorados land between 1,150 and 1,600 lbs of payload, depending on cab and trim.

GVWR (Gross Vehicle Weight Rating) is the absolute ceiling for the loaded truck itself. Curb weight plus everything you put in or on it. Excludes the trailer.

GCWR (Gross Combined Weight Rating) is the truck and the loaded trailer together. This is the number that actually governs towing math.

Tongue weight is the downward force the trailer applies to the hitch. Rule of thumb: 10 to 15% of the loaded trailer's weight. A 6,000-lb trailer means 600 to 900 lbs pressing down on your hitch, and that weight counts against your payload.

2025 Colorado Trim	Max Tow (lbs)	Max Payload (lbs)
WT (base Turbo)	3,500	~1,580
LT (Turbo Plus, properly equipped)	7,700	~1,520
Trail Boss	7,700	~1,330
Z71	7,700	~1,310
ZR2	6,000	~1,150

This is where owners get burned. Say you're at the 7,700-lb tow limit. That means 770 to 1,155 lbs of tongue weight. Add two adults (400 lbs), a cooler (60 lbs), and gear in the bed (200 lbs). You're at 1,400 to 1,800 lbs of payload before you hook up. A Trail Boss is already over its payload number even though the tow rating looks fine. The NHTSA vehicle safety and load rating standards cover the regulatory side of this. The short version: the door sticker rules.

Decoding Your Tow Rating: Door Sticker vs. Owner's Manual vs. Advertised Specs

This is the section nobody else writes, and it's the one that matters most.

You'll see three different tow numbers for your truck depending on where you look:

1. Chevy's website or brochure: the maximum advertised rating. This is the best-case truck with specific block, specific drivetrain, specific cab, and all options checked.

2. Owner's manual: towing chart with combinations. Closer to your truck, but still generic.

3. Door jamb sticker: the certified rating for YOUR truck. This is the legal one.

A real example from r/GoRVing: a 2022 Colorado 2WD shortbed Z71 owner posted that their door sticker showed a 5,800-lb limit. A VIN decoder suggested 7,000 lbs with a weight distribution hitch. They were stuck between three numbers and didn't know which to trust.

The answer is always the door jamb sticker. Open the driver's door, look at the white sticker on the B-pillar or door frame, and find the lines for GVWR and tow rating. That's your truck. A weight distribution hitch is a stability tool. It does not raise your certified tow rating. Same goes for aftermarket airbags, hitch upgrades, or a tuner. None of it changes the number on the sticker.

Another forum thread captured it well: one owner with a 2.8L manual realized their max trailer weight changed from 1,800 lbs to 2,300 lbs. The difference was whether they had the 3.42 or the 3.73 axle ratio. Same block, same trim, same year. Different rear gear, different rating. The sticker is the only place that confirms which one you have. While you're checking that label, you can also use it to look up your Chevy Colorado trim code for matching covers and accessories.

How Drivetrain Choice (2WD vs. 4WD) Affects Your Colorado's Tow Rating

The 2WD version of any given Colorado trim usually carries a slightly higher tow rating than the 4WD. The math is simple: a transfer case, front diff, front axles, and front driveshafts add weight. More truck weight means less left over for the trailer under the GCWR ceiling.

In the second-generation, you'd typically see a 100 to 300 lb gap between 2WD and 4WD on the same block. In the current generation, Chevy advertises the 7,700-lb max for both, but only with specific cab and bed combinations. Crew Cab Short Box and Crew Cab Long Box have different ratings even within the same trim. Don't assume. Check the door sticker.

If you're cross-shopping a 2022 Chevy Colorado used and a 2025 new, the drivetrain spec is on the build sheet for both.

Protecting Your Colorado's Interior When the Work Gets Real

Towing 6,500 lbs of camper to the lake means muddy work boots grinding into the driver's seat bolster. A greasy tow strap coils on the back bench. A lab mix sheds on every surface for two days straight. Factory cloth takes the hit. After three seasons, the driver's seat looks sandblasted. The dye fades in a stripe where your left knee pivots getting in. The foam compresses where the tow strap has been riding against it for months.

By the time most owners notice, the seam has already split. Dealership reupholstery quotes hit $1,400 fast.

That's the moment made-to-fit covers earn their keep. Our made-to-fit luxury seat covers for the 2026 Chevrolet Colorado are tailored to factory seat dimensions and airbag-safe. They're cut for side-airbag deployment and install in under an hour with the seats still bolted to the floor. Priced around half of dealership upholstery. Same thinking applies to a 2024 Colorado or any other year. Covers are cut to that specific seat shape.

If you want the full breakdown on materials and fit before you commit, our truck seat cover guide for working pickups walks through eco-leather vs. fabric. Our common seat wear problems for truck owners post covers what actually fails first. Browse the broader range of truck and car seat cover options if you've got more than one rig in the driveway. Go straight to the made-to-fit luxury seat covers if you already know what you want.

For wet environments or muddy work, check out our waterproof seat cover buying guide. Learn more about best ways to protect your truck interior year-round.

Frequently Asked Questions

Q: Which Chevy Colorado can tow 7,000 lbs or more?

Any current-generation Colorado (2023-2026) with the 2.7L TurboMax and factory trailering package hits 7,700 lbs. In the second generation, the 3.6L V6 reached around 7,000 lbs and the 2.8L Duramax diesel hit 7,700 lbs. Trail Boss, Z71, and properly equipped LT trims all qualify. The ZR2 caps at 6,000 lbs because of its off-road suspension. The base 2.5L four-cylinder and the entry-level 2.7L Turbo don't get there.

Q: Are Chevy Colorados good for towing?

Yes. At 7,700 lbs max, the Colorado sits at the top of the midsize truck class. The TurboMax puts down 430 lb-ft of torque, which handles most boats, campers, and work trailers without breaking a sweat. The eight-speed automatic and integrated trailer sway control make highway towing stable. If you regularly tow more than 7,000 lbs, step up to a Silverado 1500. The Colorado will do it, but the transmission won't love you long-term.

Q: Does a weight distribution hitch increase towing capacity?

No. A weight distribution hitch redistributes tongue weight between the truck's front axle, rear axle, and trailer axles. It improves stability, reduces sag, and makes towing safer at the upper end of your rating. It does not raise the certified tow number. Your maximum towing capacity is fixed by the manufacturer at the time of build and printed on the door jamb sticker. No bolt-on accessory changes it.

Q: Why is my door sticker tow rating different from what Chevy advertises?

Chevrolet advertises the maximum possible rating for a given model. That's the best-case build with every right option. Your door sticker reflects the certified rating for your exact truck, its specific block, drivetrain, cab size, axle ratio, and installed packages. A 2WD short-bed Z71 without the trailering package will show a much lower number than the 7,700-lb headline figure. The sticker is always the number to trust.

Q: What is the towing capacity of the Chevy Colorado diesel?

The 2.8L Duramax turbo-diesel, available in second-generation Colorados from 2016 through 2022, enabled a 7,700-lb tow rating. That was the highest in that generation and the first time a Colorado hit that number. The current-generation truck dropped the diesel in favor of the 2.7L TurboMax, which matches the same 7,700-lb ceiling using a turbocharged gas four-cylinder with 430 lb-ft of torque. If you want the diesel, you're shopping used.

Q: How do I find my Colorado's exact towing capacity?

Open the driver's side door and look at the compliance sticker on the door jamb or B-pillar. It lists your truck's certified GVWR, axle ratings, and maximum towing capacity based on how it was actually built. Not the best-case advertised figure. You can also pull the build sheet from your VIN through Chevy's owner site. The sticker is the legally binding number, so trust it over any decoder, brochure, or dealership claim.
